. 16 Answers SOURCE: Do you need to change times on your bell schedule or change what schedule you're on?

Dukane Acc5 Administrative Control Console Manual
Dukane Mcs350 Intercom
Dukane Starcall System Manual

To change times go to your master phone press system, enter passcode, scroll by pressing next until you see programmed events, press select, you will see Event 1 this represents your first bell press select to change it. Scroll until you see tm, press select, enter the time, press enter. Then press exit it will bring you back to Event 1 press next it will bring you to Event 2 that is for your 2nd bell program it like you did the first event.

If you need to change the schedule get into the system like you do for events and press next until you see time schedule enter the schedule ou would like to use for that day and press enter. If you need more assistance visit our website at Westexaudioelectronics.com Posted on Aug 17, 2011. Keypad/User Interface Failure A fault code of 'F' then '1' flashes when there is a primary control failure.

Standby mode if there is a user interface mismatch. DISPLAY (Saved Code) EXPLANATION AND RECOMMENDED PROCEDURE Console and Indicators This test is performed when any of the following situations occurs during the Console and Indicators Diagnostic Test: None of the indicators light up No beep sound is heard Some buttons do not light indicators None of the indicators light up: 1. Perform steps in Accessing & Removing the Electronic Assemblies, and visually check that the P11 connector is inserted all the way into the machine/motor control. Visually check that the user interface assembly is properly inserted in the console assembly 3. If both visual checks pass, replace the user interface assembly. Plug in washer or reconnect power.

Activate the Console and Indicators Diagnostic Test mode to verify repair. If indicators still do not light, the machine/ motor control has failed: Unplug washer or disconnect power. Replace the machine/motor control assembly. Plug in washer or reconnect power. Activate the Console and Indicators Diagnostic Test mode to verify repair. No beep sound is heard: 1.

Perform steps in Accessing & Removing the Electronic Assemblies, and visually check that the P5 connector is inserted all the way into the machine/motor control. If visual check passes, replace the user interface assembly. Plug in washer or reconnect power. Activate the Console and Indicators Diagnostic Test mode to verify repair.

If replacing the user interface assembly failed: Unplug washer or disconnect power. Replace the machine/motor control assembly. Plug in washer or reconnect power. Activate the Console and Indicators Diagnostic Test mode to verify repair.

Some buttons do not light indicators: 1. Perform steps in Accessing & Removing the Electronic Assemblies, and visually check that the console electronics and housing assembly is properly inserted into the front console. If visual check passes, replace the user interface assembly. Plug in washer or reconnect power. Activate the Console and Indicators Diagnostic Test mode to verify repair. To Access/replace the CCU: #1 Unplug the Whirlpool Cabrio power cord from the wall outlet.

Turn off the water supply to the washing machine. Pull the washer away from the wall so that you can access the screws behind the control console. Remove the hex head screws securing the control console to the washer with a nut driver. The screws are on the lower rear edge of the control console. #2 Lift the control console up, and rotate the console forward so that the face of the console is resting on the top of the washer.

Locate the interface board cable connector to the right of the plastic tube on the back of the console. Pull the end of the connector straight out of the control console.

The primary machine control is the box that the plastic tube connects. #3 Place small pieces of masking tape around the nine wires connecting to the primary machine console. Label the wire locations onto the masking tape with a pencil. Grasp each wire at the connector with your fingers, and pull the wires away from the primary control. Pull the plastic tube out of the primary control. #4 Locate the nut toward the bottom of the primary control. Remove the nut with a nut driver.

Lift the front of the primary control slightly, and slide it down to disengage the retaining clips. Pull the primary control out of the control console. Insert the new primary control into the control console. Slide the primary control up to engage the lower clips. Secure the primary control to the console with the single hex head screw. #5 Push each of the wire connectors into their respective positions on the primary control until they lock into place. Push the plastic tube hose over the port on the right side of the primary control.

Remove the small pieces of masking tape from the wires. #6 Position the control console back upright on the top of the washer. Secure the control console to the washer with the three hex head retaining screws. Slide the washer back against the wall.

Turn on the water supply and plug the washer into the wall outlet. TECH SHEET LINK: Thanks for using FixYa - a 4 THUMBS rating is appreciated for answering your FREE question.#$% May 05, 2010. E11 Fill time too long. Refer to test (1). E13 Water leak in tub or air leak in air bell.

Refer to test (2). E21 Water not pumping out fast enough.

Refer to test (3). E23 Drain pump relay on control board failed, wire off pump or pump Replace console control board, wire or defective.

E24 Drain pump relay on control board failed. Replace console control board. E31 Pressure sensor not communicating with control board. Refer to test (4). E35 Pressure sensor indicates water overfill. Refer to test (5).

E36 Console control board problem. Replace console control board.

E38 Air chamber clogged or pressure sensor defective. Check air chamber, rpl press. E41 Control board thinks the door switch is open.

Refer to test (6). E43 Console control board thinks the door locking device has failed. Refer to test (7). E44 Console control board problem. Replace console control board. E45 Console control board problem. Replace console control board.

E46 Console control board problem. Replace console control board. E47 Console control board thinks the door PTC circuit is open in spin. Refer to test (7). E48 Console control board thinks the door PTC circuit is closed. Refer to test (7).

E52 Bad signal from tacho generator. Refer to test (8).

E56 High motor current. Refer to test (9). E57 High current on inverter. Refer to test (9). E58 High current on motor phase. Refer to test (9).

E59 No tacho signal for 3 seconds. Refer to test (10). E5A High temperature on heat sink caused by overloading. Test first-if bad-rpl speed control brd. E5B High temperature on heat sink. Replace speed control board. E5C High temperature on heat sink.

Replace speed control board. E5D Communication problem. Refer to test (11). E5E Communication problem. Refer to test (11). E5F Communication problem.

Refer to test (11). E66 Heating element relay failure. Refer to test (14). E67 Input voltage on microprocessor incorrect.

Refer to test (15). E68 Current leakage to ground on heater or fuse opened. Refer to test (14 & 15).

E71 Wash NTC failure. Refer to test (15). E74 Wash temperature does not increase. Wire off NTC - rpl water valve. E75 Water temperature sensor circuit. Refer to test (12). E82 Console control board problem.

Replace console control board. E83 Console control board problem.

Replace console control board. E91 Comunnication error between UI board and console control board. Refer to test (16).

E93 Console control board problem. Replace console control board. E94 Console control board problem. Replace console control board. E95 Communication error. Replace console control board. E97 Console control board problem.

Replace console control board. E98 Console control board problem. Replace console control board. EB1 Incoming power frequency out of limits.

User manual for the galaxy s3. Refer to test (13). EB2 Incoming line voltage above 130 VAC. Check voltage at outlet.

If 90VAC, replace the console control board. EBE Console control board problem. Replace console control board. EBF Console control board problem. Replace console control board.

EF1 Clogged drain pump. Unclog the drain pump. EF2 Too much soap.

Advise customer to reduce the amount of soap they are using. Apr 24, 2010. Keypad/User Interface Failure A fault code of 'F' then '1' flashes when there is a primary control failure.

You will need to replace the machine/motor control assembly. Page 14 and 16, in the manual link below will help you with this. F then 2 flashes when in: Diagnostics Test mode if a stuck key is detected. Standby mode if there is a user interface mismatch. DISPLAY (Saved Code) EXPLANATION AND RECOMMENDED PROCEDURE Console and Indicators This test is performed when any of the following situations occurs during the Console and Indicators Diagnostic Test: None of the indicators light up No beep sound is heard Some buttons do not light indicators None of the indicators light up: 1. Perform steps in Accessing & Removing the Electronic Assemblies, and visually check that the P11 connector is inserted all the way into the machine/motor control.

Visually check that the user interface assembly is properly inserted in the console assembly 3. If both visual checks pass, replace the user interface assembly. Plug in washer or reconnect power. Activate the Console and Indicators Diagnostic Test mode to verify repair. If indicators still do not light, the machine/ motor control has failed: Unplug washer or disconnect power.

Replace the machine/motor control assembly. Plug in washer or reconnect power. Activate the Console and Indicators Diagnostic Test mode to verify repair.

No beep sound is heard: 1. Perform steps in Accessing & Removing the Electronic Assemblies, and visually check that the P5 connector is inserted all the way into the machine/motor control. If visual check passes, replace the user interface assembly. Plug in washer or reconnect power. Activate the Console and Indicators Diagnostic Test mode to verify repair. If replacing the user interface assembly failed: Unplug washer or disconnect power.

Replace the machine/motor control assembly. Plug in washer or reconnect power.

Activate the Console and Indicators Diagnostic Test mode to verify repair. Some buttons do not light indicators: 1. Perform steps in Accessing & Removing the Electronic Assemblies, and visually check that the console electronics and housing assembly is properly inserted into the front console.

If visual check passes, replace the user interface assembly. Plug in washer or reconnect power. Activate the Console and Indicators Diagnostic Test mode to verify repair. To Access/replace the CCU: #1 Unplug the Whirlpool Cabrio power cord from the wall outlet. Turn off the water supply to the washing machine.

Pull the washer away from the wall so that you can access the screws behind the control console. Remove the hex head screws securing the control console to the washer with a nut driver. The screws are on the lower rear edge of the control console. #2 Lift the control console up, and rotate the console forward so that the face of the console is resting on the top of the washer. Locate the interface board cable connector to the right of the plastic tube on the back of the console. Pull the end of the connector straight out of the control console. The primary machine control is the box that the plastic tube connects.

#3 Place small pieces of masking tape around the nine wires connecting to the primary machine console. Label the wire locations onto the masking tape with a pencil.

Grasp each wire at the connector with your fingers, and pull the wires away from the primary control. Pull the plastic tube out of the primary control. #4 Locate the nut toward the bottom of the primary control. Remove the nut with a nut driver. Lift the front of the primary control slightly, and slide it down to disengage the retaining clips. Pull the primary control out of the control console. Insert the new primary control into the control console.

Slide the primary control up to engage the lower clips. Secure the primary control to the console with the single hex head screw.

#5 Push each of the wire connectors into their respective positions on the primary control until they lock into place. Push the plastic tube hose over the port on the right side of the primary control.

Slide the washer back against the wall. Turn on the water supply and plug the washer into the wall outlet. TECH SHEET LINK: Thanks for using FixYa - a 4 THUMBS rating is appreciated for answering your FREE question. Dec 02, 2009. To Access/replace the switch: #1 Unplug the Whirlpool Cabrio power cord from the wall outlet.
